HIGH TEMPERATURE PLUG & SOCKET-OUTLET (150°C permanent) – 125 A – 440 V – IP44 – IK09 – METAL
This DS high temperature plug & socket is approved for normal operation up to a continuous ambient temperature of 240°C.
It can therefore be used to supply electrical equipment located close to heat sources: machines, industrial installations, steelworks, metallurgy, etc.
Highlights
- High-temperature environment up to 240°C
- Metal casing, IK09
- Automatic IP44
Characteristics
Download the catalogueStandards
- European Low Voltage and RoHS Directives (CE marking), European REACH Regulation.
- Ensures that electrical machines comply with the European 'Machinery' Directive in respect of disconnecting switches.
- Ensures that electrical installations comply with the decrees of 30 August 2010, 22 September 2010 and the decrees implementing the French Labour Code relating to health and safety at work when using electrical installations.
- Ensures that electrical installations comply with national regulations on worker protection in Belgium, Spain and Italy.
- Ensures electrical installations comply with IEC/HD 60364 and NF C 15-100 electrical installation standards.
